EW테mls-micro SwiteN《eae(∈DW Serise

Replacing the common 19.8mm × 10.6mm microswitch on the market at present, it adopts a simple and stable spring structure to achieve high life and high availability. The 0.1A~5A microswitch has a wide range of varieties and a variety of terminal forms.

It has a variety of auxiliary operating handles and can be installed in a variety of ways using a integrally formed terminal structure that does not spread solder upward; Especially in line with safety standards in North America and Europe. Uses: coffee machines, juice machines, blenders, gas stove ignition switches, intelligent products, printers, and other equipment

■ Coding Rule Ratings

⑨ Contact type: 5 (3) A1/4HP125/250VAC No identification: silver alloy 32) A1/8HP125/250VACAG: silver alloy 2: 2A125/250VACG: silver alloy gold plating 01: 0.1A125/250VAC3C: silver plating

② Drive lever type Housing and material Button 00: Without drive lever No identification: PBT housing and button 01: 16.6mm Direct drive lever 02: 186mm Direct drive lever 03: 24.7mm Direct drive lever

⑦ Button color 04: 17.9mm Hook type drive lever No identification: Black W: White 05: 166mm Roll type drive lever For specific appearance, please refer to the drive lever information column

③ Terminal type

① Housing color N: N-type soldering wire terminal without identification: Black W: White P: P-type pin terminal G: Gray C: Left bend plug-in sub D: Right bend plug-in terminal L: # 110 wiring terminal

⑤ Action Force (OF) Acrylic

④ Contact type unmarked: dual throw type 110:110gf2: normally open type 3: normally closed type See operating force table 0: dual throw type (usually omitted)
